- Emotion
Power input: 24VDC 10/100 T-based Ethernet interface Pulse/Direction or CW/CCW Differential output (max. 8MPPS) Encoder ABZ (max. 12MHz) Home/FWD/REV limit inputs Servo On/Alarm Clear outputs Breakpoint/Position Capture functions Trapezoidal and S-curve velocity profile Linear/circular/helical interpolation & multi-axes sync move Support Python, C# and LabVIEW
|
|
- EDrive-ST
Power input: 24VDC 10/100 T-based Ethernet interface For 2-phase stepper motor Microstepping: 51200 steps/rev (adjustable) Max. supply voltage: 36V Max. current: output 2.1A, peak 5A Encoder ABZ (nominal: 8MHz) Home/FWD/REV limit inputs Stall detection/intelligent energy saving/diagnostic function 8-pt ramp acceleration smoothing Support Python, C# and LabVIEW
|
|
- STEM
10/100 T-based Ethernet interface 4-slot IDC-50P 3.3V DIO Support modules: 24ch-24V-DI/ 24ch-24V-DO/ 12-12ch-24V-DIO/ 24ch-5V-TTL/ 24ch-AIO 24ch-2-wire-Multiplexer/4x6-Matrix switch Support Python, C# and LabVIEW
|
|
- EthanA
Power input: 24VDC 10/100 T-based Ethernet interface AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 20kHz Input range: +/-10V Support Python, C# and LabVIEW
|
|
- EthanA2
Power input: 24VDC 10/100 T-based Ethernet interface AI: 8ch simultaneous & 24-bit single-ended Max. sampling rate: 10kHz Input range: +/-13.75V Support Python, C# and LabVIEW
|
|
- EthanD
Power input: 24VDC 10/100 T-based Ethernet interface DO: 6ch NPN/PNP, opto-isolated 24V DI: 8ch NPN/PNP, opto-isolated 24V 2ch PWM outputs Support Python, C# and LabVIEW
|
|
- EthanEX_D
Power input: 24VDC 10/100 T-based Ethernet interface DO: 16ch NPN/PNP, opto-isolated 24V DI: 16ch NPN/PNP, opto-isolated 24V 2ch PWM outputs 2ch counter Support Python, C# and LabVIEW
|
|
- EthanI
Power input: 24VDC 10/100 T-based Ethernet interface Current input: 8ch multiplexed & 24-bit Update rate: 1.2kHz (1ch) Input range: +/-20mA Support Python, C# and LabVIEW
|
|
- EthanIA
Power input: 24VDC 10/100 T-based Ethernet interface Current input: 8ch multiplexed & 24-bit Voltage input: 8ch multiplexed & 24-bit Update rate: 600Hz (1ch) Current input range: +/-20mA Voltage input range: +/-25V Support Python, C# and LabVIEW
|
|
- EthanL
Power input: 24VDC 10/100 T-based Ethernet interface 6ch high-quality mechanical relay 4ch form-A (NO) + 2ch form-C (NO+NC) Max. current: 1A Operating time: 2ms (excluding bounce) Release time: 1ms (excluding bounce) Support Python, C# and LabVIEW
|
|
- EthanO
Power input: 24VDC 10/100 T-based Ethernet interface AO: 8ch simultaneous & 16-bit single-ended Output range: +/-10V Max. update rate: 1kHz Support function generation Support Python, C# and LabVIEW
|
|
- EthanP
Power input: 24VDC 10/100 T-based Ethernet interface 4ch variable digital potentiometers Output range: 300-50kΩ Max. update rate: 500Hz Support Python, C# and LabVIEW
|
|
- EthanT
Power input: 24VDC 10/100 T-based Ethernet interface 7ch thermocouple inputs Sensor type: K, J, N, R, S, T, E, & B Settling time: 160ms (1ch) Support Python, C# and LabVIEW
|
|
- USBDAQF1D
USB 2.0 full-speed bus powered 26ch 3.3V DIO (5V-tolerant) I2C/SPI/UART/PWM/counter Support Python, C# and LabVIEW
|
|
- USBDAQF1AD
USB 2.0 full-speed bus powered 20ch 3.3V DIO (5V-tolerant) I2C/SPI/UART/PWM/counter AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 16kHz (1ch) Input range: +/-10V Support Python, C# and LabVIEW
|
|
- USBDAQF1DSNK
USB 2.0 full-speed bus powered DO: 12ch NPN, opto-isolated 24V DI: 14ch NPN, opto-isolated 24V PWM/counter External 24VDC power required Support Python, C# and LabVIEW
|
|
- USBDAQF1TD
USB 2.0 full-speed bus powered 21ch 3.3V DIO (5V-tolerant) I2C/SPI/UART/PWM/counter 2ch thermocouple inputs Sensor type: K, J, N, R, S, T, E, & B Support Python, C# and LabVIEW
|
|
- USBDAQF1RD
USB 2.0 full-speed bus powered 21ch 3.3V DIO (5V-tolerant) I2C/SPI/UART/PWM/counter 2ch RTD inputs Support PT-100 or PT-1000 Support Python, C# and LabVIEW
|
|
- USBDAQF1CD
USB 2.0 full-speed bus powered 20ch 3.3V DIO (5V-tolerant) I2C/SPI/UART/PWM/counter CAN V2.0B at 1Mb/sec Support Python, C# and LabVIEW
|
|
- USBDAQF1AOD
USB 2.0 full-speed bus powered 16ch 3.3V DIO (5V-tolerant) I2C/SPI/UART/PWM/counter AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 16kHz (1ch) Input range: +/-10V AO: 8ch simultaneous & 16-bit single-ended Output range: 0-5V Support Python, C# and LabVIEW
|
|
- WifiDAQE3A
AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 10kHz Input range: +/-10V Web-based configurator 802.11 b/g/n WiFi 2.4 GHz to 2.5 GHz Support Python, C# and LabVIEW
|
|
- WifiDAQE3AH
AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 10kHz Input range: +/-10V Built-in 9DoF IMU with posture estimation Web-based configurator 802.11 b/g/n WiFi 2.4 GHz to 2.5 GHz Support Python, C# and LabVIEW
|
|
- WifiDAQE3AOD
AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 10kHz Input range: +/-10V AO: 8ch simultaneous & 16-bit single-ended Output range: 0-5V DO: 8ch NPN, opto-isolated 24V DI: 8ch NPN, opto-isolated 24V Web-based configurator 802.11 b/g/n WiFi 2.4 GHz to 2.5 GHz Support Python, C# and LabVIEW
|
|
- WifiDAQF4A
AI: 8ch simultaneous & 16-bit single-ended Max. sampling rate: 20kHz Input range: +/-10V Web-based configurator 802.11 b/g/n WiFi 2.4 GHz to 2.5 GHz Support Python, C# and LabVIEW
|
|
